3M Mini-Clamp 2mm Board Mount Connector - 4 positions, 20-22awg, Gray
3M Mini-Clamp 2mm Board Mount Connectors feature insulation displacement termination and offer a time-saving, reliable, filed-installable wiring solution.
Product Overview
3M Mini-Clamp 2mm Board Mount Connectors feature insulation displacement (IDC) termination and offer a time-saving, reliable, filed-installable wiring solution. The simple installation process minimizes the risk of conductor damage with no wire stripping/peeling of the cable jacket or special tools. These single-row connectors offer 2.54mm row spacing and a 2mm pitch in 3, 4, or 8 positions and support 28AWG to 20AWG, 32V, 3.0A maximum wires. The 3M Mini-Clamp 2mm Board Mount Connectors are ideal for sensor, LED, switch, and various small device connections in industrial equipment and manufacturing facility applications.
Features & Specs
- Type: Clamp Socket
- Number of Positions: 4 Position
- Pitch: 2 mm
- Number of Rows: 1 Row
- Mounting Style: Panel Mount
- Termination Style: IDC
- Mounting Angle: Straight
- Contact Gender: Socket (Female)
- Contact Plating: Gold
- Wire Gauge: 22 AWG to 20 AWG
- Minimum Operating Temperature: - 20 C
- Maximum Operating Temperature: + 85 C
- Brand: 3M Electronic Solutions Division
- Contact Material: Copper Alloy
- Current Rating: 3 A
- Flammability Rating: UL 94 V-0
- Housing Color: Black
- Housing Gender: Socket
- Housing Material: Thermoplastic (TP)
- Insulation Resistance: 1 MOhms
- Latching Type: Latch Holder
- Voltage Rating: 32 V
Documentation
Customer Reviews
Stock and Customer Discounts
Available Discounts
- $4.70 | 25+ units
- $4.46 | 100+ units
