EFR32BG21 Blue Gecko Wireless SoC - 76.8 MHz, 2.4G, 8dB, Build-in antenna, 25 GPIO
These modules are based on EFR32BG22 System-On-Chip (SoC) modules and enable Bluetooth® Low Energy (BLE) connectivity.
Product Overview
Silicon Labs BGM220P/BGM220S Wireless Gecko Bluetooth Modules are built to meet the performance, security, and reliability requirements of battery-powered IoT products running on Bluetooth networks. These modules are based on EFR32BG22 System-On-Chip (SoC) modules and enable Bluetooth® Low Energy (BLE) connectivity. The Bluetooth modules deliver the best RF range and performance, future-proof capability for a feature and OTA firmware updates, enhanced security features, and low energy consumption. These BGM220P/220S modules are a full solution that comes with fully-upgradeable, robust software stacks, world-wide regulatory certifications, advanced development, and debugging tools.
The modules offer support that will minimize and simplify the engineering and development of end-products and help to accelerate their time-to-market. Typical applications include portable medical, connected home, wellness device, asset tags, and beacons.
Features & Specs
- Up to 8dBm TX power
- 1.8V to 3.8V wide operating range
- -98.9dBm BLE RX sensitivity at 1Mbps
- 32-bit ARM Cortex-M33 core at up to 76.8MHz
- Up to 25 GPIO pins
- -40°C to 105°C operating temperature range
- 12.9mm x 15mm size
Documentation
Customer Reviews
Stock and Customer Discounts
Available Discounts
- $10.40 | 25+ units
- $9.86 | 100+ units
