Gravity UV Sensor Module
DFRobot Gravity VEML6075 UV Sensor Module adopts the individual UVA and UVB channel solution with 16-bit resolution.
Product Overview
DFRobot Gravity VEML6075 UV Sensor Module adopts the individual UVA and UVB channel solution with 16-bit resolution. This sensor module converts solar UV light intensity into digital data and provides an accurate measure of the signal strength. The VEML6075 sensor module provides a reliable performance of UV radiation measurement under long time solar UV exposure. This sensor offers -40°C to 85°C range of excellent temperature compensation capability. The Gravity VEML6075 module operates at 3.3V to 5V operating voltage range.
The VEML6075 UV sensor module features low power consumption and the minimum power can be as low as 800nA in shut-down mode. This UV sensor is used in portable electronic products, wearable devices, weather stations, and flame detectors.
Features & Specs
- 3.3V - 5V operating voltage range
- PH2.0-4P interface
- 0x10 IIC address
- 22mm × 30mm product size
- 3mm mount hole size
- 15mm mount hole pitch
- Response wavelength:
- UVB (λ0.5) within 315nm to 340nm response wavelength
- UVA (λ0.5) within 350nm to 375nm response wavelength
- -40°C to 85°C operating temperature range
