J-Link 9-Pin Cortex-M Adapter
PGM-18522
J-Link 9-Pin Cortex-M Adapter
SKU: PGM-18522
Out of stock
SKU
PGM-18522
The 9-Pin Cortex-M Adapter allows JTAG, SWD, and SWO connections between J-Link or Flasher and Cortex-M based target hardware systems.
Product Overview
The 9-Pin Cortex-M Adapter allows JTAG, SWD, and SWO connections between J-Link or Flasher and Cortex-M based target hardware systems. It adapts from the 20-pin 0.1'' JTAG connector to a 9-pin 0.05'' Samtec FTSH connector as defined by Arm.
The 9-Pin Cortex-M Adapter may also be used to connect J-Link or Flasher to a non-Cortex-M target as far as the target connector uses the same pinout. By default, TRST is not connected, but the Cortex-M Adapter comes with a solder bridge (NR1) which allows TRST to be connected to pin 9 of the Cortex-M adapter.
Similar Items
Documentation
Customer Reviews
J-Link 9-Pin Cortex-M Adapter
PGM-18522
Stock and Customer Discounts
$44.95 retail price.
Available Discounts
- $42.70 | 25+ units
- $40.46 | 100+ units
