Laird Connectivity BL653µ Nordic nRF52833 Module - Trace pin
WRL-17651
Laird Connectivity BL653µ Nordic nRF52833 Module - Trace pin
SKU: WRL-17651
Out of stock
SKU
WRL-17651
Laird Connectivity BL653µ Nordic nRF52833 Modules target space-constrained applications to implement longer-range BLE in harsh operating environments.
Product Overview
Laird Connectivity BL653µ Nordic nRF52833 Modules target space-constrained applications to implement longer-range BLE in harsh operating environments. The BL653µ modules are low-power microcontrollers with multi wireless capabilities ideal for wireless Internet of Things (IoT) connectivity. The devices are powered by the Nordic nRF52833 Multi-Protocol System-on-Chip. They provide maximum development flexibility with programming options for the Nordic SDK or Zephyr RTOS, AT command set, and Laird Connectivity’s smartBASIC environment.
Similar Items
Features & Specs
- Ultra-small footprint
- Integrated Antenna (6.3mm x 8.6mm x 1.6mm)
- Trace Pad Option (6.3mm x 5.6mm x 1.6mm)
- Bluetooth v5.1 Bluetooth Low Energy (BLE) plus NFC
- 802.15.4 radio (non-certified) –ZigBee / Thread via nRF Connect SDK or Thread via Zephyr)
- Widest range of configurable interfaces: UART, I2C, I2S, SPI, ADC, GPIO, PWM, FREQ, USB, PDM, and NFC
- Extended Industrial Temperature Rating (-40° to +105°C)
- Bluetooth Low Energy - Peripheral/Central roles supported
- 2Mbps and LE Long Range: Support for 2Mbps, 1Mbps, & 125Kbps coded PHY
- Bluetooth 5.1 - Direction finding – AoA and AoD
- Hostless operation – Internal MCU reduces BOM
- Powerful Core Cortex-M4F (512kB Flash, 128k RAM)
- Built on years of experience with Nordic (BL600, BL652 & BL654 Series)
- Application design choice: Leverage Laird Connectivity’s smartBASIC, simple AT command set, Zephyr RTOS or utilize * Nordic SDK directly
- Nordic nRF52833 – 3.175mm x 3.175mm WLCSP with 32 GPIOs utilized
Documentation
Customer Reviews
Laird Connectivity BL653µ Nordic nRF52833 Module - Trace pin
WRL-17651
Stock and Customer Discounts
$9.95 retail price.
Available Discounts
- $9.45 | 25+ units
- $8.96 | 100+ units
