Texas Instruments TPS562207 2A Synchronous Buck Converter
Texas Instruments TPS562207 2A Synchronous Buck Converter is a simple, easy-to-use, 2A synchronous buck converter in a SOT563 package.
Product Overview
Texas Instruments TPS562207 2A Synchronous Buck Converter is a simple, easy-to-use, 2A synchronous buck converter in a SOT563 package. The device is optimized to operate with minimum external component counts and also optimized to achieve low standby current. This switch-mode power supply (SMPS) device employs D-CAP2 mode control providing a fast transient response. It supports both low-equivalent series resistance (ESR) output capacitors such as specialty polymer and ultra-low ESR ceramic capacitors with no external compensation components.
Texas Instruments TPS562207 operates in Forced Continuous Conduction Mode (FCCM), which maintains a fixed switching frequency and output voltage ripple is very small. TPS562207 is available in a 6-pin 1.6mm × 1.6mm SOT563 (DRL) package and specified from a –40°C to 125°C junction temperature.
Features & Specs
- Mounting Style: SMD/SMT
- Package / Case: SOT-563-6
- Output Voltage: 804 mV to 7 V
- Output Current: 2 A
- Number of Outputs: 1 Output
- Input Voltage MAX: 17 V
- Topology: Buck
- Input Voltage MIN: 4.3 V
- Switching Frequency: 580 kHz
- Minimum Operating Temperature: - 40 C
- Maximum Operating Temperature: + 125 C
